    Paper Edge Angle Punching Cutter Machine Frequency Control Pulled Smoothly

    Ask Lasest Price
    Brand Name : tiansheng
    Model Number : high speed
    Certification : ISO9001
    Price : Price negotiation
    Payment Terms : T/T
    Supply Ability : 5set per month
    Delivery Time : 45
    • Product Details
    • Company Profile

    Paper Edge Angle Punching Cutter Machine Frequency Control Pulled Smoothly

    Paper edge angle board punching cutter machine Paper Punching Machine


    Product introduction


    1. The paper loading part is a right-angle hanging paper rack. The right-angle paper holder saves space, and the paper is pulled smoothly. The paper is hoisted with an electric type, which is easy to operate and saves labor.
    2. Independent glue supply system is pneumatic automatic glue application for diaphragm pump. The speed of glue supply can be controlled by adjusting the air pressure, and the method is simple and easy to operate.
    3. The host is an eight-component type, and the pressure wheel depth of each component can be adjusted by manually adjusting the cylinder (the cylinder is adjustable); the pressure can be controlled by the pressure regulating valve according to the thickness of the angle of protection, and the operation modes are all Extremely simple.
    4. The plastic tank and the coated tray are made of stainless steel, which has corrosion resistance and wear resistance, which greatly enhances the service life of the plastic tank. A separate glue-coated tray for each layer of paper avoids the problem of easy paper break. The glue scraper is a step-type glue scraper, which also plays an important role in solving the paper break problem.
    5. The conveying device after the corner protector is convenient for the bundling and transportation of the corner protector.


    technical parameter


    Paper Angle Protection Specification
    Wide20-100mm
    Long30-9000mm
    Thick2-8mm

    Production speed

    0-10m/min (angle protection length 50-100mm)

    0-40m/min (guard angle longer than 1500mm)

    Host power
    7.5kw+4.3kw*2

    Control mode

    Frequency control

    Raw material

    The surface of the paper 150g-200g

    Core paper 300g-700g

    Cutting mode

    Automatic cutting

    Number of operators
    1-2people
