1600c High Speed Paper Slitting And Rewinding Machine High Practical Value

Fucheng Tiansheng paper tube machinery Co.,Ltd
Contact Now
    Buy cheap 1600c High Speed Paper Slitting And Rewinding Machine High Practical Value from wholesalers

    Buy cheap 1600c High Speed Paper Slitting And Rewinding Machine High Practical Value from wholesalers
    • Buy cheap 1600c High Speed Paper Slitting And Rewinding Machine High Practical Value from wholesalers
    • Buy cheap 1600c High Speed Paper Slitting And Rewinding Machine High Practical Value from wholesalers

    1600c High Speed Paper Slitting And Rewinding Machine High Practical Value

    Ask Lasest Price
    Brand Name : Tiansheng
    Model Number : 1600C
    Certification : ISO9001
    Price : Price negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 10+SET/SETS+per month
    Delivery Time : 40-45
    • Product Details
    • Company Profile

    1600c High Speed Paper Slitting And Rewinding Machine High Practical Value

    1600C High speed paper roll cutting machine slitter rewinder machine


    Machine introduction


    1. The paper winding method is the inflatable shaft retractable type. Inflatable shaft take-up paper completely avoids the phenomenon of the conventional take-up paper roll and shaft disengagement.
    2. The unique slitting structure of the bending roller completely avoids the paper overlapping phenomenon during rewinding. The curvature of the bending roller can be adjusted at any time according to the paper.
    3. Pneumatic paper unloading after rewinding saves labor, and is convenient and fast.
    4. Independent operation of the electric box is conducive to the operation of the entire machine. Its main executive components are Chint products; the cylinder components are Tian'ao Soupai products. These are China's old-fashioned products, which have the characteristics of durability and high practical value.


    Technical parameter



    Model

    TSFQ-1600C High speed cutting machine

    Technical parameter

    Synchronization controller

    Parent roll width
    1600(mm)
    Major Executing Devices (Contactors, etc.)

    CHINT

    Parent roll diameter
    1200(mm)
    Button

    Siemens

    Emergency stop

    Siemens

    Rewind diameter
    1200(mm)
    knob

    Siemens

    Slit width
    >35(mm)
    Signal elements (proximity switches, etc.)

    Hugong

    Slitting capability
    80-600g
    Cylinder element
    CEHNGDI/SUOPAI/TIANAO

    The main power
    11kw
    Hydraulic system

    Special-purpose

    Paper on the way
    Hydraulic Shaftless Support
    Frequency converter

    ENERGY

    Number of cutter
    1818pcs
    Configuration device

    Winding way

    Gas up outside the closed

    Charging

    Hydraulic lift system Electric clamping

    Paper down the way

    Hydraulic blanking

    Blanking

    Hydraulic blanking

    Speed of adjust and control

    Frequency control

    Adjusting knife mode

    Manual adjustment

    Speed of Slitting
    1-300(m/min)
    Tension regulation

    Pneumatic brake

    Power input
    380V 220V
    Rewinding of Single Air Rising Shaft

    Operator
    1
    Double-knife slitting, thickened blade


    main point

    All of our machines will be tested and had trial production in our factory before leaving our factory and they are shipped out only after customers are satisfied with them. Customers can send your technicians or the Third party inspection agency to our factory to check and accept machines before delivery.
